Export HTTP Trigger Callback URLs for Power Automate Flows

Summary

This script fetches HTTP trigger callback URLs for Power Automate flows in a specified environment and exports the results to a CSV file. It checks prerequisites, logs into Microsoft 365 CLI and Azure, retrieves flows, and collects callback URLs for each flow.

• CLI for Microsoft 365

# Check if Modules are installed.

# Ensure Az.Accounts module is available
if (-not (Get-Command m365 -ErrorAction SilentlyContinue)) {
    Write-Host "Microsoft 365 CLI not found." -ForegroundColor Yellow
    Write-Host "Please install manually using npm:" -ForegroundColor Cyan
    Write-Host "npm install -g @pnp/cli-microsoft365" -ForegroundColor Cyan
    Write-Host "(Requires Node.js: https://nodejs.org)" -ForegroundColor Cyan
    # Continue anyway, but 'm365' commands will fail if not installed
}else {
    Write-Host "Microsoft 365 CLI is available." -ForegroundColor Green
}

# Ensure Az.Accounts module is available
if (-not (Get-Module -ListAvailable Az.Accounts)) {
    Write-Host "Az.Accounts module not found. Installing..." -ForegroundColor Yellow
    try {
        Install-Module Az.Accounts -Scope CurrentUser -Force -AllowClobber
        Write-Host "Az.Accounts module installed successfully." -ForegroundColor Green
    }
    catch {
        Write-Host "Failed to install Az.Accounts. Please install manually with:" -ForegroundColor Red
        Write-Host "Install-Module Az.Accounts -Scope CurrentUser -Force" -ForegroundColor Cyan
    }
}else {
    Write-Host "Az.Accounts module already available." -ForegroundColor Green
}

# Import Az.Accounts
Import-Module Az.Accounts -ErrorAction SilentlyContinue


# ===============================
# Global Variables
# ===============================

# Environment ID
$environmentId = "6e123fe123c14-a15f-eeda-1122-d1232f712323fe09"

# API URL for Flow
$flowUrl = "https://api.flow.microsoft.com"

# Output path
$outputCsv = "C:\testpath\ProdFlows_Output.csv"

# Number of flows to process
$maxFlowsToProcess = 50

# ===============================
# Main Script
# ===============================

# Step 1: Log in to Microsoft 365 CLI (interactive)
Write-Host "Ensure you're logged into Microsoft 365 CLI (run 'm365 login' before running this script)" -ForegroundColor Cyan

# Step 2: Get all flows in environment
$allFlows = m365 flow list --environmentName $environmentId --asAdmin --output json | ConvertFrom-Json

# Step 3: Take first N flows (or less if total < N)
$flows = $allFlows | Select-Object -First $maxFlowsToProcess
Write-Host "Processing $($flows.Count) flows (max requested: $maxFlowsToProcess)" -ForegroundColor Yellow

# Step 4: Login to Azure to fetch access token
Login-AzAccount -UseDeviceAuthentication
$accessToken = (Get-AzAccessToken -ResourceUrl "https://service.flow.microsoft.com/").Token

# Step 5: Prepare results array
$results = @()

# Step 6: Loop through each flow and fetch callback URL
foreach ($flow in $flows) {
    $flowId        = $flow.name
    $flowName      = $flow.properties.displayName
    $flowState     = $flow.properties.state
    $createdTime   = $flow.properties.createdTime
    $modifiedTime  = $flow.properties.lastModifiedTime
    $ownerId       = $flow.properties.creator.userId


    # --- Fetch full flow details ---
    $flowDetails = m365 flow get --name $flowId --environmentName $environmentId --asAdmin --output json | ConvertFrom-Json

    $triggerKind   = $flowDetails.triggers

    Write-Host "Fetching trigger URL for Flow: $flowName ($flowId)" -ForegroundColor Cyan

    $newTriggerUrl = ""
    $path = "providers/Microsoft.ProcessSimple/environments/$environmentId/flows/$flowId/triggers/manual/listCallbackUrl?api-version=2016-11-01"

    try {
        $response = Invoke-RestMethod -Uri "$flowUrl/$path" `
            -Method POST `
            -Headers @{
                "Authorization" = "Bearer $accessToken"
                "Content-Type"  = "application/json"
            }

        # Parse response schema
        if ($response.response.value) {
            $newTriggerUrl = $response.response.value
        }
        elseif ($response.'$content') {
            $newTriggerUrl = $response.'$content'
        }
    }
    catch {
        Write-Host "Failed to fetch trigger URL for Flow: $flowId" -ForegroundColor Red
    }

    # Add new property to results
    $results += [PSCustomObject]@{
        FlowId        = $flowId
        FlowName      = $flowName
        State         = $flowState
        CreatedTime   = $createdTime
        ModifiedTime  = $modifiedTime
        OwnerId       = $ownerId
        TriggerType   = $triggerKind
        NewTriggerURL = $newTriggerUrl
    }
}

# Step 7: Export results
$results | Export-Csv -Path $outputCsv -NoTypeInformation -Force
Write-Host "Report generated at: $outputCsv" -ForegroundColor Green
# ...existing code...

Check out the CLI for Microsoft 365 to learn more at: https://aka.ms/cli-m365

Important changes coming to the way you login into CLI for Microsoft 365 (effective 9th September 2024) see Changes in PnP Management Shell registration in Microsoft 365

Contributors

Author(s)
Siddharth Vaghasia
